Set Burr-Bi

SetBurrB

This heavy-duty tool set includes 2 double-sided round R10 HSS blades for extended tool life. Excellent for work on hard and soft materials. Ideal for sheet-metal up to 16 mm (0.63 inch). Handguard for worker safety included.

Holder Burr-Bi


R
10 X 2

Holder Burr-Bi

Key

Side A - For spiral chip materials
Side B - For powdery chip materials

Drawing 1 - Tool in position for deburring single straight edge
Drawing 2 - Tool in position for deburring double straight edges

Set Name

Mfg. No.

Handle

Holder

Blades

Mango II Set Burr Bi

155-00206

Mango II

Burr-Bi

R10 X 2


back to top

Set D

Metal Sheet Edge Cleaner

Set D

Simple to operate! Deburrs both sides of sheets in one pass! The D80C carbide blade, featuring 6 deburring corners, can also
be used as a scraper. Perfect for sheet metal with thickness up to 3 mm. Handguard for worker safety also available.

Holder D

D80C

B80 C

Key

SetBurr DRotate the blade to the above position to turn your D80C blade into a surface scraper.

Set Name

Mfg. No.

Handle

Holder

Blades + Key

Mango II Set D

155-90064

Mango II

D

D80C


back to top

Set Burr-Ex

Couuntersink set Burr-Ex mainpic

Practical for chamfering the outer diameter of tubes up
to 26 mm (1 inch) dimaeter.
Includes Holder FR with ratchet mechanism.

F26XSetBurrEx Holder
Holder FR

Set Name

Mfg. No.

Handle

Holder

Blades

Set Burr-Ex (FRX)

155-90073

Mango II

FR

F26X

Set Burr-Ex Aluminum

155-00224

Aluminum

FR

F26X


back to top

Set HC - HandyChuck

Set HC

SHAVIV's powerful scraping tool for the toughest of applications, includes the double-sided C50 scraper blade.
The HandyChuck is a heavy-duty pin vise handle.
Use also for drills, taps, countersinks and files.

SetHC HandyChuck C50


Thinner blade C60 can be purchased separately.

Set HC 60

C60

Set Name

Mfg. No.

Handle

Blades

Set HC 5

155-00163

HandyChuck

C50

Set HC 6

155-00164

HandyChuck

C60


back to top

All Metal PlumBurr

Practical tool made out of strong metal designed to chamfer tubes on both inner and outer edges.

Tube range
:
6-41mm (0.23-1.61 inch) - Metal
4.8-38mm (0.189-1.496 inch) - Plastic

PlumBurr

Set Name

Mfg. No.

Plum-Burr Metal

155-90082

Plum-Burr Plastic

155-90083


back to top

Set U

SetU Blades

Precision Scraper
Contains 3 mini-scraper blades
Specially designed holder for extra precision work and linear movement.
Ideal for die makers.

SetU Handle
U1 Holder U

SetU Blades
U4U31

Set Name

Mfg. No.

Handle

Blades

Mango II Set U

155-00221

U

U1 (BUS1)
U31(BUS31)
U4 (BUS4)


back to top

Set K

Set K

Wide Surface Cleaner
The preferred scraper for surface cleaning.
Excellent for rust and paint removal.

K10C

Set K Holder
Holder K

Set Name

Mfg. No.

Handle

Holder

Blades + Key

Mango II Set K

155-00207

Mango II

K

K10C


back to top

Set L

Set L

External Curved-Edge Cleaner
Tool set for the deburring of external curved edges on pipes and tubes.

L10

Set L

Holder L

Set Name

Mfg. No.

Handle

Holder

Blades + Key

Mango II Set L

155-00220

Mango II

L

L10


back to top

Specialty Blades

Blade


Description

U1 (BUS1)
151-29195

Fine-finishing triangular scraper

U2 (BUS2)
151-29196

Fine-finishing flat scraper

U31 (BUS31)
151-29197

Fine-finishing round scraper

U4 (BUS4)
151-29198

Fine-finishing hooked corner scraper

K10C
151-29062

Carbide, double-edged. Excellent for wide
surfaces up to 50 mm (1.97 Inch) in one pass.

L10
151-29063

HSS, 4 deburring edges. For outer diameter of
20 mm (0.78 Inch) and up.


back to top

Specialty Tools PDF
